Wired Touch Panels - User Manual
7© CUE, a.s. | All Rights Reserved.
On-Wall Multisurface Models
touchCUE-7-M touchCUE-10-M touchCUE-12-M
Product code CS0539 CS0561 CS0540
Display type Color a-Si TFT LCD with LED backlit Color IPS LCD with LED backlit Color a-Si TFT LCD with LED backlit
Display size 7” (177.8 mm) diagonal 10.1” (256.5 mm) diagonal 12.1” (307.3 mm) diagonal
Resolution 1280 x 800 pixels 1280 x 800 pixels 1280 x 800 pixels
Viewing angle 160° horizontal, 170° vertical 170° horizontal, 170° vertical 160° horizontal, 170° vertical
Touch overlay Projected capacitive Projected capacitive Projected capacitive
Sensors Light and proximity Light and proximity Light and proximity
Side indicators - Programmable RGB LED -
Audio Microphone and speakers Microphone and speakers Microphone and speakers
Memory RAM 512 MB,
microSD Card min. 8 GB
RAM 512 MB,
microSD Card min. 8 GB
RAM 512 MB,
microSD Card min. 8 GB
Network Wired 10/100 BaseT Ethernet Wired 10/100 BaseT Ethernet Wired 10/100 BaseT Ethernet
Power supply PoE, IEEE 802.3af / Class 0 PoE, IEEE 802.3af / Class 0 PoE+, IEEE 802.3at / Class 4
Enclosure Aluminium, edge-to edge front glass
Compatible with VESA 75 x 75 mm
Protection IP30
Aluminium, edge-to edge front glass
Compatible with VESA 75 x 75 mm
Protection IP30
Aluminium, edge-to edge front glass
Compatible with VESA 75 mm x 75 mm
Protection IP30
Dimensions 199 x 120 x 23 mm 268 x 167 x 25 mm 320 x 200 x 32 mm
Weight 0.8 kg 1.1kg 2.2 kg
Included accessories PoE power supply, Ethernet cable PoE power supply, Ethernet cable PoE+ power supply, Ethernet cable
Available extension NFC Module | CS0579 NFC Module | CS0579 -
