UK Wiring Instructions - Cuisinart
n Your Cuisinart Bread Maker includes a BS 5 amp moulded (fused) mains plug on the supply cord.
n Should it be necessary at any stage to remove this moulded plug and replace it with a re-wireable BS 13 amp
mains plug, the re-wiring should be completed as follows: (NB The moulded plug should be disposed of safely)
Class I (1) Earthed Appliance
The wires in the mains lead are coloured in accordance with the following code:
GREEN & YELLOW = EARTH
BLUE = NEUTRAL BROWN = LIVE
As the colours of the wire may not correspond with the coloured markings identifying the terminals in your plug,
proceed as follows:
n The wire which is coloured GREEN and YELLOW must be connected to the terminal in the plug which is marked
with the letter E or or coloured green or yellow or green and yellow.
n The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or
coloured black.
n The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or
coloured red.
With this appliance, if a 13 amp plug is used, a 5 amp fuse should be tted. If any other type of plug is used, a 5 amp fuse
must be tted, either in the plug or at the distribution board.
WARNING: A cut off plug inserted into a 13 amp socket is a serious safety (shock) hazard. Ensure that the cut off
plug is disposed of safely.
