Cuisinart CPG-465 - Step 21: Attaching the Drip Shield Bracket

ASSEMBLY INSTRUCTIONS
18
STEP 20
-----------------------------------------------------------------------------------
• Re-install the temperature probe cover
removed in Step 7.
STEP 21
-----------------------------------------------------------------------------------
• Attach the Drip Shield Bracket (18) to the inside of
the grill body using two sets of Screws (A), Locking
Washer (C), and Washer (B).
A
B
C
x 2
x 2
x 2
