Culver Mobility ARTEMIS User Manual

Figure 4
(4). Attach the controller to
the bracket (FIG.)
⑤.Unscrew the outside of the battery case and read the Battery Connection Diagram on the inside of the
battery case cover. There are two cables in the battery box, one side of the battery box is blue and black cable, the
other side of the battery box is red and black cable. The battery has two wires, blue and red.
The connection method for the blue and BLACK CABLES IN THE BATTERY CASE IS:
The blue cable connects the red string, and the black cable connects the red string.
The Red and black cables in the BATTERY CASE ARE CONNECTED BY:
Red Cable to red string, black cable to blue string.
®. Check the clutch handle position of the motor, that is, the handle is " off" (manual
position) when perpendicular to the wheel, and vice versa (see figure 4) . Note: There is no clutch device for
the first speed reduction motor.
©. Observe the cable located at the 1 ower part of the vehic 1 e ; if the cable is found lying on the ground, use
the attached strap bunching and lift it to a certain height (see figure 5).
INPUT
(POWER)
Power supply (red for pole, black
for - pole)
RIGHT v
Right motor/brake (heavy wire for
(MOTOR)
motor, thin wire for brake) Left
带
motor/brake; (heavy wire for motor,
(MOTOR)thin wire for brake) Charger plug
2： 3： Forbade
INPU
T
(POW
ER)
RIGHT
(MOTOR)
LEFT TO(CHARGING PORT)
(MOTOR) (CHARGER)
Figure 5
the
are
has
(§). Press the " power on" button to turn the power on, while "battery indicator"
and fiquot;speed indicator" lights turned on. "Battery Display" light means the wheelchair
power been turned on, the more light
means the more power, " speed level
di sp1ay" light has a total of 1 ower speed limit
five, full 1 ight speed, the less 1 ight the
(see figure 6).
01
