932 Use Modes
This page is a short outline of the available modes for using this interface unit.
Button Box Modes
Mode Identifier USB Serial Description Notes
000 HID KEY BYGRT HID keyboard, sends B for blue button, Y for yellow, etc.
001 HID KEY 12345 HID keyboard, sends 1,2,3, etc.
002 HID NAR BYGRT HID keyboard, same as mode 000, except keys do not auto-release
003 HID NAR 12345 HID keyboard, same as mode 001, except keys do not auto-release
051 HID KEY 1-9 NO 5 HID keyboard, like mode 001, but no 5 is sent for triggers
052 HID KEY NAR NO T HID keyboard, like mode 002, but no T is sent for triggers
053 HID KEY NAR NO 5 HID keyboard, like mode 003, but no 5 is sent for triggers
100 ASCII 12345 Sends ASCII "B" for blue button, "Y" for yellow, etc.
102 RBX Legacy support for RBX button box emulation
Trackball Modes
Mode Identifier USB Serial Description Notes
500 HID MOUSE 1 HID mouse with two buttons
503 HID COMPOSITE HID mouse with two buttons, + keyboard for trigger
550 SERMOUSE Legacy serial mouse emulation
590 TRACKBALL CAL -na- -na- Trackball gain calibration mode
Joystick Modes
Mode Identifier USB Serial Description Notes
600 HID MOUSE 1 HID mouse with two buttons
601 HID JOYSTICK/GAMEPAD HID joystick with two buttons
651 PJS Serial "Programmer's" joystick output: fast, high resolution serial output
Scroll Wheel Modes
Mode Identifier USB Serial Description Notes
200 HID KEY TGB HHSC-SCROLL-1 mode, sends T for UP. B for down
201 HID COMPOSITE HHSC-SCROLL-1 mode: mouse movements
Mis cellaneous Other Modes
Mode Identifier USB Serial Description Notes
800 LEGACY HH CAL -na- -na Gain calibration mode for legacy HH handheld devices
801 SCROLL WHEEL CAL -na- -na Gain calibration mode for scroll wheel handheld device
900 DIAGNOSTIC 1 diagnostic mode for testing
