Technical specifications for Transcutaneous Electrical Nerve
Stimulator (TENS) mode
Waveform Mono-phase square pulse wave
Pulse amplitude
Adjustable, 0~105mA peak at 1000 ohm Load each
channel, 1mA/Ste
.
Pulse Width Adjustable, from 50 to 300us microseconds, 10μS/step
Pulse Rate Adjustable, from 1 to 150 Hz, 1 Hz/step
Burst (B)
Burst rate: Adjustable, 0.5 ~ 5Hz
Pulse width adjustable,50-300uS
Frequency fixed=10Hz
Normal (N)
The pulse rate and pulse width are adjustable. It
generates continuous stimulation based on the setting
value.
Pulse Width Modulation (M)
The pulse width is automatically varied in a cycle time.
The pulse width is decreased from its original setting to
60% in setting cycle time, and then increased from
60% to its original setting in nest setting cycle time. In
this program, pulse rate (1 to 150Hz), pulse width (50
to 300us) and cycle time (5 to 30 sec) are fully
adjustable.
Pulse Rate Modulation (M1)
The pulse rate is automatically varied in a cycle time.
The pulse rate is decreased from its original setting to
60% in setting cycle time, and then increased from
60% to its original setting in nest setting cycle time. In
this program, pulse rate (1 to 150Hz), pulse width (50
to 300us) and cycle time (5 to 30 sec) are fully
adjustable.
