PARTS LIST — MODEL 11 CABLE PULLER
ITEM
NO.
PA RT NUMBER DESCRIPTION QTY.
111-001
GEARBOX
1
211-005
CAPSTAN
1
311-006
CAPSTAN END PLATE
1
411-008
RELEASE KNOB (3/8" × 1.5")
1
511-003
DRIVE SHAFT
1
611-007
DOWEL PIN (1/4" OD × 1/2")
1
711-134
KEY STOCK - 3/16" X 3/16" × 1/2"
1
811-009
MAIN FRAME
1
911-11 5
LEG ADAPTER COUPLING
1
10 11-018
LOWER FRAME
1
11 11-101
DRIVE ADAPTER
1
12 754-186
HEX SHAFT-ADAPTER
1
13 163-11
SCREW-BUTTON HEAD SOCKET (10-32 × 5/16")
4
14 2-1109
SNAP RING - 3/4"
2
15 610-25
NUT-HEX NYLON INSERT (3/8-16)
4
16 528-2
SCREW-HEX HEAD CAP GR5 ZINC (3/8-16 × 2)
2
17 450-14J
WASHER-FLAT SAE #10
2
18 11-004
ROLL PIN (1/4" OD × 2")
1
19 754-015
SCREW-HEX HEAD CAP GR5 ZINC (3/8-16 × 1.5)
1
20 11-019
WING SCREW (10-32 × 3/4")
2
21 11-027
LOCK WASHER (#10)
2
22 11 -002
SOCKET HEAD CAP SCREW (M6 × 16)
4
23 11-024
QUICK RELEASE PIN (3/8" × 1-5/16")
1
24 11 -107
STRAP CLIP
2
25 11-022
DRILL ATTACHMENT STRAP
1
26 11 -117
OUTER BOOM TUBE
1
27 11 -118
INNER BOOM TUBE
1
28 11-133
HEAD ASSEMBLY
1
29 11-033
SCREW-SET, # 10-32 × 1/8"
2
30
31
705-8
GRIP
1
32
452-27
WASHER - LOCK, 3/8
1
33
524-11
SCREW-HX HD CAP, 3/816 × 1"
1
11-010
HANDLE - ALUMINUM
1
34 747-30 NUT—HEX, THIN NYLON INSERT (1/4–20) 1
35 610-3 SCREW — HEX HD CAP, 1/4–20 × 1.75" 1
36 11-138 WASHER — 3/4" S.S. 1
37 11-139 KEY, 1/8" × 1/8" × 7/8" (INCLUDED WITH ITEM #1) 1
