10
13. Tighten the 3 screws on each side of the unit’s
door to secure the aesthetic door.
14. Adjust the bolt to loosen or tighten the
tension of the unit’s door.
15. For Wooden Worktops
Tighten the screw into the top bracket to fix it
to the wooden worktop.
For Synthetic / Ceramic Worktops
Tighten the screw into the side bracket to fix
it to the synthetic / ceramic worktop.
* All images are for indication only; please refer to your individual unit for actual item.
