INSTALLATION WALKTHROUGH:
For more information log onto www.curtmfg.com, & for helpful towing tips log onto www.hitchinfo.com
3. Raise hitch into position and loosely secure to carriage
bolts using 7/16" hex flange nuts. Note: The side plates
will slide between the inside of the tow loops.
4. Align holes in side plates with holes in tow loops and
secure using 3/8" hex bolts, 3/8" washers and 3/8" hex
flange nuts, as shown.
5. Torque all 7/16" hardware to 70 ft-lbs.
Torque all 3/8" hardware to 45 ft-lbs.
