ILLUSTRATED PARTS LIST IP42
G4TP2, ILLUSTRATED PARTS/RECOMMENDED PARTS 051618C
ITEM # PART # DESCRIPTION
1 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
2 WC-61509 COVER, TOP TP2S
3A WC-820WDR
1
VALVE, DUMP RIGHT 120V 12W W/INTERNAL
RESISTOR & DIODE
3B WC-854
2
VALVE, BREW DUMP RIGHT 240V 12W GEM12D/
TP/TPC
4A WC-2977K
a
KIT, SPRAYHEAD FITTING METAL
4B WC-2977-101K
b
KIT, SPRAYHEAD FITTING PLASTIC
5 WC-3417-P
BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED GEMIN HOT COFFEE
6A WC-442
1
SOLENOID, LOCK BREW CONE RIGHT/LEFT
120V TP2T/TP2S/GEMSS/GEM
6B WC-446
2
SOLENOID, LOCK BREW CONE RIGHT 220V
THERMOPRO/GEMTS
7A WC-844-101
1
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
7B WC-844-102
2
VALVE, BY-PASS, 240V NON-ADJUSTABLE W/
RESTRICTOR (WC-2945)
8 WC-10000 CONTROL MODULE, TOUCH SCREEN G4
9 WC-10001 CONTROL MODULE, UPM 120/220V G4
10 WC-8559
RELAY, SOLID STATE 280V/40A W/ HEATSINK
AND QUICK DISCONNECTS
11 WC-58037-101 COVER, CENTER WRAP TP 90 DEG
12 WC-596
2
FILTER, NOISE EMI 250VAC/30A 1PH
13 WC-1825 FAUCET, ASSY HOT WATER TP2S
14 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE
15A WC-3528
1
LEG, 4" ADJUSTABLE 3/8-16 THRD ITALIAN
STYLE
15B WC-3500T
2
LEG, 4” ADJUSTABLE W/TIE DOWNS 3/8-16
THRD
16A WC-589-101
1
TRANSFORMER,120VAC-24V 4.8A W/ LEADS &
MOLEX CONNECTOR
16B WC-589-102
2
TRANSFORMER,240VAC- 24V 4.8VA W/LEADS &
MOLEX CONNECTOR
17 WC-2402P-P ELBOW, 3/8”FL x 3/8” NPT PLATED
18 WC-1501 FUSE, HOLDER ASSY W/5A FUSE
19 WC-14045-101 CURRENT SENSOR ASSY G4
ITEM # PART # DESCRIPTION
1 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
3A WC-820WDR
VALVE, DUMP RIGHT 120V 12W W/INTERNAL
RESISTOR & DIODE
6A WC-442
SOLENOID, LOCK BREW CONE RIGHT/LEFT
120V TP2T/TP2S/GEMSS/GEM
7A WC-844-101
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
9 WC-10001 CONTROL MODULE, UPM 120/220V G4
G4TP2S - Recommended Parts to Stock
ITEM # PART # DESCRIPTION
20 WC-103
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
21A WC-847
1
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
21B WC-883
2
VALVE, INLET 2 GPM 240V 6W
22 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
23A WC-1200
1
CORD, 14/3 SJTO 6’ BLK W/PLUG
23B WC-1250
2
CORD, 4mm² 90ºC 49A 450/750V 6 FT LG W/
FERRULES ONE END
24 WC-5231 COMPOUND, HEAT SINK 5OZ
25 WC-314 POWER BLOCK, 5 STATION
26 WC-10008 UNIVERSAL HOST ADAPTER USB
27 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
28 WC-29044-101 SLEEVE, OVERFLOW
29A WC-37132
KIT, VALVE REPAIR FOR INVENSYS WC-
820WDR,WC-821WDR, WC-844WDR (OLDER
UNITS)
29B WC-37132-101
KIT, VALVE REPAIR FOR DELTROL
WC-820WDR,WC-821WDR, WC-844WDR
(NEWER UNITS)
30A WC-13462
1
HARNESS ASSY G4TP2S
30B WC-13462-101
2
HARNESS, COMPLETE G4TP2S30’S EXPORT
VERSION (INCLUDES TERMINAL BLOCK)
31A WC-4320
a
O’RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
#112
31B WC-43089
b
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
EPDM 70 SHORE
32A WC-4213-P
a
NUT, 5/8 LOCK PLATED
32B WC-4212-02
b
NUT, 5/8-18 JAM PLASTIC
33 WC-4412 SCREW, 10-32x3/16” PH PN HD MS SS
34 WC-4503 SCREW, 8-32x1/2 PHILLIPS HEAD
35 WC-4426 SCREW, 8-32x3/8 PH HEAD TRUSS
36 WC-4514 SCREW, 8-32x3/8 PAN HEAD PH SS
37 WC-4458
SCREW, 6-19 x 1/2” PHIL PAN HD TRI-LOBULAR
60-1 THRD FORMING
38 WC-1805
SEAT CUP, “S” FAUCET USE ON WC-1800/B/
LB/D/DL/L/WC-1803
ITEM # PART # DESCRIPTION
14 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE
19 WC-14045-101 CURRENT SENSOR ASSY G4
21A WC-847
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
22 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
G4TP2S - Main Chassis - Parts List
1
G4TP2S10A3500, G4TP2S63A3100, G4TP2S63A3500,
2
G4TP2S30A3100
a
8QLWVEXLOWDQGODWHU6WDLQOHVVVWHHOÀWWLQJNLW$LVFRPSDWLEOHZLWKROGHUXQLWV
b
Units built before 05/15/17.
