Curtis ThermoPro G4 Series User Manual

ELECTRICAL SCHEMATICS ES49
GTPSG4-10, ELECTRICAL SCHEMATIC 062519C
1
120Vac Hot Input
1
12 Vac I nput
2
120Vac Hot Input
2
12 Vac I nput
3
Brew Valve
3
Tank Water Level Probe
4
Not Used
4
Vdd +5Vdc
5
120Vac Neutral
5
Not Used
6
Inlet Valv e
6
Tank Temperature Sensor
7
Not Used
7
Tank Temperature Sensor
8
Not Used
8
(Data_Communicat ion Next)
Not Used
9
Not Used
9
Vss- (Logic_Common)
10
Not Used
10
Solid St at e Relay +5Vdc
11
Brew Cone Lock
11
Data_Communication First
12
Not Used
12
Not Used
13
Warmer
13
Solid St at e Relay - Common
14
Not Used
14
UPM Ground
15
Bypass
Valve
16
Not Used
17
Not Used
18
Not Used
19
Current Sensor
20
Current Sensor
1
12 Vac Input (Back Light)
1
TX - Transmit
2
Vdd +5Vdc
2
RX - Receive
3
Vss- (Logic_Common)
3
Not Used
4
Not Used
4
Vdd +5Vdc
5
12 Vac Input (Back Light)
5
Vss- (Logic_Common)
6
Dat a_Communicat ion First
7
Not Used
8
Not Used
1
Vss- (Logic_Common)
2
TX - Transmit
3
Vdd +5Vdc
4
RX - Receive
5
Not Used
6
Not Used
(UCM TOUCH SCREEN) Pin Assignments
(USB) Pin Assignments
6-Pin Connector
(UPM) Pin Assignments
rotcennoC niP 41rotcennoC niP 02
rotcennoC niP 5rotcennoC niP 8
Model
Voltage
V
Amps
A
WaƩs
W
Hertz
Hz
# of
Conductor
Wires
Phase
# of Tank
Elements
Tank Element
RaƟng
W/V
Warmer
Element
RaƟng
W/V
208 18.3 3800
220 19.5 4300
240 20.8 5000
208 18.3 3800
220 19.5 4300
240 20.8 5000
208 18.5 3850
220 19.5 4300
240 21.5 5150
208 17.3 3600
220 18.6 4100
240 19.4 4660
2000W/220V -
V021/W001V022/W000221306/0501SMEG4G
21306/0501S2CPT4G
ELECTRICAL RATING TABLE
-V022/W
000221306/0501S2PT4G
2000W/220V -21306/0501S1PT4G
SINGLE, DOMESTIC, 220 VOLT
