ILLUSTRATED PARTS LIST IP42
G4TP2, ILLUSTRATED PARTS/RECOMMENDED PARTS 051618C
ITEM # PART # DESCRIPTION
1A WC-820WDR
1
VALVE, DUMP RIGHT 120V 12W W/INTERNAL
RESISTOR & DIODE
1B WC-854
2
VALVE, BREW DUMP RIGHT 240V 12W GEM12D/
TP/TPC
2A WC-821WDR
1
VALVE, DUMP LEFT 120V 12W W/INTERNAL
RESISTOR & DIODE
2B WC-853
2
VALVE, BREW DUMP LEFT 240V 12W GEM12D/
TP/TPC
3A WC-442
1
SOLENOID, LOCK BREW CONE RIGHT/LEFT
120V TP2T/TP2S/GEMSS/GEM
3B WC-446
2
SOLENOID, LOCK BREW CONE RIGHT 220V
THERMOPRO/GEMTS
4A WC-2977K
a
KIT, SPRAYHEAD FITTING METAL
4B WC-2977-101K
b
KIT, SPRAYHEAD FITTING PLASTIC
5A WC-844-101
1
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
5B WC-844-102
2
VALVE, BY-PASS, 240V NON-ADJUSTABLE W/
RESTRICTOR (WC-2945)
6A WC-37132
KIT, VALVE REPAIR FOR INVENSYS WC-
820WDR,WC-821WDR, WC-844WDR (OLDER
UNITS)
6B WC-37132-101
KIT, VALVE REPAIR FOR DELTROL
WC-820WDR,WC-821WDR, WC-844WDR
(NEWER UNITS)
7 WC-10000 CONTROL MODULE, TOUCH SCREEN G4
8 WC-10001 CONTROL MODULE, UPM 120/220V G4
9 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
10 WC-8559
RELAY, SOLID STATE 280V/40A W/ HEATSINK
AND QUICK DISCONNECTS
11 WC-3417-P
BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED GEMIN HOT COFFEE
12 WC-58037-101 COVER, CENTER WRAP TP 90 DEG
13 WC-2402P-P ELBOW, 3/8”FL x 3/8” NPT PLATED
14 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
15 WC-14045-101 CURRENT SENSOR ASSY G4
16A WC-13450
1
HARNESS ASSY, COMPLETE G4TP2T
(INCLUDES TERMINAL BLOCK)
16B WC-13450-101
2
HARNESS ASSY COMPLETE G4TP2T G4TPC2T/
G4GEMT/G4TP1T-30’S (INCLUDES TERMINAL
BLOCK)
ITEM # PART # DESCRIPTION
17 WC-29044-101 SLEEVE, OVERFLOW
18 WC-1250
2
CORD, 4mm² 90ºC 49A 450/750V 6 FT LG W/
FERRULES ONE END (NOT SHOWN)
19A WC-847
1
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
19B WC-883
2
VALVE, INLET 2 GPM 240V 6W
20 WC-596
2
FILTER, NOISE EMI 250VAC/30A 1PH
21 WC-1501 FUSE, HOLDER ASSY W/5A FUSE
22A WC-102
1
SWITCH, TOGGLE NON-LIT SPST 15A 125/6A
250VAC RESISTIVE
22B WC-103
2
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
23 WC-5459 COVER, TOP SS THERMOPRO
24A WC-3528
1
LEG, 4” ADJUSTABLE 3/8-16 THRD ITALIAN
STYLE
24B WC-3500T
2
LEG, 4” ADJUSTABLE W/TIE DOWNS 3/8-16
THRD
25 WC-1825 FAUCET, ASSY HOT WATER TP2S
26 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
27 WC-5231 COMPOUND, HEAT SINK 5OZ
28 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
29A
1
WC-589-101
TRANSFORMER,120VAC-24V 4.8A W/ LEADS &
MOLEX CONNECTOR
29B
2
WC-589-102
TRANSFORMER,240VAC- 24V 4.8VA W/LEADS &
MOLEX CONNECTOR
30 WC-10008 UNIVERSAL HOST ADAPTER USB
31A WC-4320
a
O’RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
#112
31B WC-43089
b
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
EPDM 70 SHORE
32A WC-4213-P
a
NUT, 5/8 LOCK PLATED
32B WC-4212-02
b
NUT, 5/8-18 JAM PLASTIC
33 WC-314 POWER BLOCK, 5 STATION
34 WC-4503 SCREW, 8-32x1/2 PHILLIPS HEAD
35 WC-4426 SCREW, 8-32x3/8 PH HEAD TRUSS
36 WC-4514 SCREW, 8-32x3/8 PAN HEAD PH SS
37 WC-4458
SCREW, 6-19 x 1/2” PHIL PAN HD TRI-LOBULAR
60-1 THRD FORMING
38 WC-1805
SEAT CUP, “S” FAUCET USE ON WC-1800/B/
LB/D/DL/L/WC-1803
39 WC-4412 SCREW, 10-32x3/16” PH PN HD MS SS
G4TP2T - Main Chassis - Parts List
ITEM # PART # DESCRIPTION
1A WC-820WDR
VALVE, DUMP RIGHT 120V 12W W/INTERNAL
RESISTOR & DIODE
2A WC-821WDR
VALVE, DUMP LEFT 120V 12W W/INTERNAL
RESISTOR & DIODE
3A WC-442
SOLENOID, LOCK BREW CONE RIGHT/LEFT
120V TP2T/TP2S/GEMSS/GEM
5A WC-844-101
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
8 WC-10001 CONTROL MODULE, UPM 120/220V G4
ITEM # PART # DESCRIPTION
9 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
15 WC-14045-101 CURRENT SENSOR ASSY G4
19A WC-847
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
26 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
28 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
G4TP2T - Recommended Parts to Stock
1
G4TP2T10A3100, G4TP2T10A3500,
2
G4TP2T30A3100
a
8QLWVEXLOWDQGODWHU6WDLQOHVVVWHHOÀWWLQJNLW$LVFRPSDWLEOHZLWK
older units.
b
Units built before 05/15/17.
To Next Page
