8
Innovating SMART Hose Assembly Solutions Since 1979
• While bleeding the hose, hold the opposite end of the hose higher than the manifold block. This forces
the air out the end of the hose.
Once a steady stream of water is exiting the end of the hose, either cap the end of the hose o󰀨 or use
the needle valve included to close the end of the hose.
• Place the supplied rubber mat over the hose(s). This will help contain the hose and ends if a hose failure
occurs.
• Lower the tank lid and make sure the latch engages to ensure it is fully closed.
• Begin the test.
• Begin raising the air pressure regulator (Air Drive Throttle) until the desired test pressure has been
achieved.
Note: The high pressure pump is driven by air pressure. As the air pressure is increased using the regula-
tor (throttle), the water pressure will increase. The more air pressure supplied, the higher the test pressure.
• When the test cycle is complete, check over the test result page and print the test receipt if desired.
Note: Once the test result page has been passed, a test receipt can no longer be printed.
• Open the cabinet lid and remove the hose(s).
TEST BENCH CONNECTIONS / OPERATION
