2.23.4 OPS Specifications
Operational Specifications
Parameter Specifications
Operating Wavelength 1550 ±50
Insertion Loss
T1 and T2 → Tx
< 3.8 dB
Rx → R1 and R2
< 1.2 dB
Return Loss > 45 dB
Crosstalk > 55 dB
Wavelength dependent loss < 0.1 dB
Polarization dependent loss < 0.1 dB
Monitor operating range
Tx: -30 to +25 dBm
Rx: -50 to +10 dBm
Monitor accuracy ±0.5 dB
Monitor resolution 0.1 dB
Switching speed < 25 ms
Switching type Latched when power off
Lifetime 1,000,000 cycles
Connectors LC/UPC
Dimensions 19-inch L: 483 mm W: 23 1mm H: 43.7 mm
Power Consumption < 5 W
Interface RJ-45 Ethernet
Environmental Specifications
Parameter Operational Specification Storage Specification
Temperature 0º to 50º C (32º to 122º F) 0º to 75º C (32º to 167º F)
Relative humidity
</= 85% (at 25º C) </= 85%
Atmospheric pressure 70 Kpa to 106 Kpa 70 Kpa to 106 Kpa
Operational conditions No corrosive or solvent gas.
No fly ash.
No strong electromagnetic field interference.
n/a
Power supply voltage Nominal -48 Vdc. Range -36 to -72 Vdc. n/a
2.24 XFP, SFP, and SFP+ Transceivers
For detailed specifications of supported XFP, SFP, and SFP+ transceivers and their operating parameters,
refer to the Cyan Central CyStore application located through the Cyan website at www.cyaninc.com
