Copyright © 2018 Cyber Power Systems, Inc.
EXTENDED BATTERY MODULES CONFIGURATION
The UPS can be configured to reflect the correct estimated run-times for the number of EBM installed by using the LCD Control
Panel to select the number of EBM installed.
1. Press the “ENTER” button to activate the “MAIN MENU”.
2. Press the “▲” and “▼” buttons to scroll to the “Configure” option.
3. Press the “ENTER” button to select the “Configure” submenu.
4. Press the “▲” and “▼” buttons to scroll to the “EBM Number” option.
5. Press the “ENTER” button to select the “EBM Number” submenu.
The first configuration number will be displayed on the second column of LCD display.
6. Press the “▲” and “▼” buttons to scroll through the number of attached EBM.
7. Press the “ENTER” button to select the number of EBM installed.
You may be prompted to save the selection, if so press the “ENTER” button to save the setting.
8. Press the “ESC” button to cancel or return to the previous LCD menu.
