Cybertek CP8000 Series User Manual

Shenzhen Zhiyong Electronics Co., Ltd
15
Fig 14 CP8500A Maximum continuous input measurement Fig 15 CP8500A Input Impedance-Frequency Curve
Mechanical characteristics
Model
CP8030B/H
CP8050A
CP8150A
CP8300A
CP8500A
Measurement conductor
diameter max.
5mm
20mm
Cable length
1m
1.5m
Cable length(CK-310)
100cm
Adapter dimensions(CK-612)
72*62*31mm Wire length: 1.5m
Clamp dimensions（L*W*H）
75*40*18mm
175*68*29mm
Termination unit（L*W*H）
119*49*28mm
Probe weight
255g
555g
525g
525g
Environmental characteristic
Operating temperature
and humidity
0-40℃,80% or less
Storage temperature
and humidity
-10-50℃,80% or less
Operating altitude
2000m
Storage altitude
12000m
