Cybertek HCP8030C User Manual

Shenzhen Zhiyong Electronics Co., Ltd
8
HCP8030D
30Arms
(Figure2.c)
HCP8150A
150Arms
（
Figure8.b
）
HCP8300A
300Arms
(Figure11.b)
HCP8030H
30Arms
(Figure2.d)
Max peak current
value
50Apk
75Apk
300Apk
500Apk
750Apk
Range
5A
1X
7.5A
1X
30A
10X
50A
10X
75A
10X
30A
10X
50A
10X
150A
100X
300A
100X
500A
100X
Overload
5A
≥5APk
7.5A
≥7.5APk
30A
≥30APk
50A
≥50APk
75A
≥75APk
30A
≥50APk
50A
≥75APk
150A
≥300APk
300A
≥500APk
500A
≥750APk
Current transfer
ratio
5A
1V/A
7.5A
1V/A
30A
0.1V/A
50A
0.1V/A
75A
0.1V/A
30A
0.1V/A
50A
0.1V/A
150A
0.01V/A
300A
0.01V/A
500A
0.01V/A
measurable
current
5A
1mA
7.5A
1mA
30A
10mA
50A
10mA
75A
10mA
30A
10mA
50A
10mA
150A
100mA
300A
100mA
500A
100mA
Amplitude
accuracy
(DC,45-66Hz )
5A
±1%±1mA
7.5A
±1%±1mA
30A
±1%±10mA
50A
±1%±10mA
75A
±1%±10mA
30A
±1%±10mA
50A
±1%±10mA
150A
±1%±100mA
300A
±1%±100mA
500A
±1%±100mA
Input
impedance
HCP8030
Reference
(Figure3.a)
Reference(Figure6)
HCP8150
Reference
(Figure9.a)
HCP8300
Reference
(Figure12.a)
Reference(Figure15)
HCP8030C
Reference
(Figure3.b)
HCP8030D
Reference
(Figure3.c)
HCP8150A
Reference
(Figure9.b)
HCP8300A
Reference
(Figure12.b)
HCP8030H
Reference
(Figure3.d)
Delay
time
Probe
14ns
14ns
HCP8150
36ns
41ns
42ns
HCP8150A
30ns
BNC
(1m)
5ns
Terminal load
≥100kΩ
Power supply
DC 12V/1A
（
Standard Adaptor
）
Voltage of
insulated wire
300V CATI
600V CATII 300V CATIII
Safety compliance
EN61010-1: 2010+A1:2019 EN 61010-2-032:2019
EMC standard
EN61326-1:2013 EN61000-3-2:2014 EN61000-3-3:2013
Fig 1 .a HCP8030 Fig 1 .b HCP8030C
Amp- Frequency curve Amp- Frequency curve
