Cybex Free Weight 16000 Adjustable Bench Owner’s Manual
Page 10
ITEM QTY PART NO. DESCRIPTION
1 1 08229 PIN,DETENT
2 2 11040-440 KNOB
3 4 12100-303 BUMPER
4 1 16000-200 FRAME
5 1 16000-201 CUSHION PLATE
6 1 16000-202 DETENT PLATE
7 1 16000-203 DETENT PLATE
8 1 16000-300 CUSHION PLATE
9 1 16000-318 SHAFT, PIVOT
10 1 16000-328 DECAL, ADJUSTMENT
11 1 16000-329 DECAL, ADJUSTMENT
12 1 16000-332 COVER PLATE
13 1 16010-311 FOOT PAD
14 2 16030-309 GRIP
15 1 3900-445 DECAL, CYBEX BLACK
15 1 3900-446 DECAL CYBEX SILVER
16 2 4605-509 GRAB GRIP
17 2 4605-550 PLUG .250-20 SMALL
18 1 51198 WARRANTY BOOK (NOT SHOWN)
19 2 5437-305 BUMPER
20 1 8510-366 DETENT PIN
21 2 BS070201 COM SPRING .56 x .66 1.50 LG
22 8 FB050211 BRG FLG .38 X .50 .25 LG
23 4 HC620414 BHSCS .250-20 X .625
24 1 HC700417 BHSCS .375-16 X 1.00
25 2 HC702816 SHCS .375-16 X .875
26 4 HF449063 INSERT 3/4 X 1/4-20
27 2 HN664900 NUT, HEX SELF-LOCKING .312-18 ZINC
28 2 HN704901 LOCKNUT, .375-16 NYLON
29 2 HN704902 LOCKNUT, .375-16 NYLON
30 2 HS010000 WASHER, SCREW CAP BLACK 3-8
31 2 HS328300 LOCKWASHER SPLIT .312
32 4 JC700422 BHSCS .375-16 X 1.50
33 2 JD343320 S BOLT .375 X 1.25 .312-18
34
5 JS347400 LOCKWASHER, INT TOOTH .375
35 2 PP080005 SCREW, .375, CAP, BLK
36 2 PP130004 INSERT, DOMED PLASTIC
37 2 WW130000 WHEEL, 3 IN DIA.
38 1 4800-180 BACK/W WEAR COVER
39 1 4800-183 WEAR COVER
40 1 5220-364-X* DECAL, WARNING
41 2 8500-028-X* DECAL, CAUTION
42 1 4800-168 SEAT PAD
43 1 11040-790 DECAL, MADE IN USA
*Language Key
1-German
2-French
3-Spanish
4-English
6-Japanese
7-Swedish
8-Russian
To Next Page
