CYBEX 16000 - Service and Parts; Exploded View and Parts Identification

Cybex Free Weight 16000 Adjustable Bench Owner’s Manual
Page 9
Please refer to the next several pages for parts lists, exploded-view diagrams.
6 - Service
NOTE: All inspections
and repairs must be
performed by trained
service personnel only.
Cybex will void warranty if
non-Cybex replacement parts
are used.
ADJUSTABLE BENCH
PRODUCT NO. 16000
A. Warning Label .................... 5220-364-X
B. Caution Decal .................... 8500-028-X
C. Grip................ .................... 16030-309
D. Insert Domed Plastic.......... PP130004
E. Grab Grip........................... 4605-509
DESCRIPTION PART NO.
F. Back Pad w/Wear Cover ... 4800-180
G. Wear Cover ....................... 4800-183
H. Seat Pad ........................... 4800-168
I. Serial Number Decal
J. Wheel.................................. WW130000
DESCRIPTION PART NO.
H
G
A
C, D
(both sides)
B
F
B
E
NOTE: See exploded-view diagram for location of I (serial number decal).
J
(both sides)
