Cybex Arc Trainer 750A/750AT Owner’s Manual
31
Verify handle assemblies are now installed in the correct position.8.
Right
Handle
Assembly
Correct Position
Left
Handle
Assembly
750AT
Connect 750AT contact heart rate cable
Locate contact heart rate cable exiting from the right handle assembly.1.
Heart Rate
Wire
Main Frame
Socket
NOTE: Position plug so handle
does not rub cable
during operation.
750AT
Plug right heart rate cable into main frame socket. Refer to the above diagram.2.
