CYBEX Eagle User Manual

Cybex Eagle Leg Press Owner’s Manual
1 1 11040-202 FOOT PLATE
2 1 11040-203 LINKAGE
3 1 11040-205 SEAT
4 1 11040-206 CUSHION PLATE
5 1 11040-213 FRAME
6 1 11040-215 PIVOT
7 1 11040-218 CAM
8 1 11040-219 PIVOT
9 1 11040-220 FRAME
10 1 11040-222 OUTER ADJUSTING TUBE
11 1 11040-227 ADJUSTING BAR
12 2 11040-225 COATED BEARING HOUSING
13 1 11040-301 CLAMP BLOCK INSERT
14 1 11040-321 P/ADJUSTING ARM
15 2 11040-344 SHAFT
16 2 11040-440 KNOB
17 2 11040-752 EXT INC WT CHANNEL
18 2 11040-755 EXTRUDED GUARD
19 2 11040-753 EXT INC WT CHANNEL
20 1 11040-770 COVER, TOP
21 1 11040-768 COVER, TOP
22 2 11040-776 CHASSIS
23 2 11040-777 TRAY, BOTTOM
24 2 11040-763 PANEL, SHROUD FRONT
25 1 11040-761 PANEL, SHROUD BACK
26 2 11040-499 P/CHANNEL
27 1 11040-529 SHAFT, PIVOT
28 1 11040-530 SHAFT, PIVOT
29 2 11040-531 WT ROD .625 DIA X 64.50
30 1 11040-551 DECAL, ADJUSTING
31 1 11040-553 HANDLE SHAFT
32 2 11040-554 GLIDE
33 2 11040-557 P/SPACER
34 1 11040-560 DECAL, WEIGHT PLATE (10 - 290)
35 1 11040-561 DECAL, WEIGHT PLATE (310- 490)
36 1 11040-562 NON-SLIP
37 1 11040-563 SHIELD
38 1 11040-610-X* PLACARD, EAGLE LEG PRESS
39 1 11040-999-X* OWNERS’ MANUAL
40 2 11050-375 PIVOT PIN
41 2 11080-337 SHAFT PIVOT
42 2 11090-369 SHAFT, PIVOT
43 2 11090-374 END CAP
44 2 11090-376 RING, HANDLE GRIP
45 5 11090-392 FOOT COVER
46 1 3900-441 DECAL, CYBEX INTERNATIONAL
47 1 4605-381-X* WARNING LABEL
48 4 4000Y316-X* DECAL, CAUTION
49 2 4505-331 BUMPER, 1.50 DIA
50 1 4605-322 PIN, DETENT
51 1 4605-511 INSERT,PLASTIC 5.94
52 1 51198 WARRANTY BOOK (NOT SHOWN)
53 1 8500-025-X* DECAL, CAUTION
54 2 8500-026-X* DECAL, CAUTION
55 1 8500-028-X* DECAL, CAUTION
56 1 9100-314 CYLINDER, DAMPNER
57 2 9100-315 CLIP, DAMPNER SAFETY
58 4 BR030203 RETAINING RING
59 2 BR030210 RETAINING RING, 17mm
60 2 BR030212 RETAINING RING, 1.575 INTERNAL
61 4 BR030214 RETAINING RING, .625 DIA
62 2 BS070201 COM SPRING .56 x .66 1.50 LG
63 1 CM000211 DECAL, PATENT PENDING
ITEM QTY PART NO. DESCRIPTION
64 10 FB030232 BEARING, RADIAL 17 mm EXT. RACE
65 4 FB110200 BRG, LINEAR 1.50
66 6 FB130207 BRG FLG 17mm X 19mm X 25mm
67 4 FS110200 SEAL, LINEAR BEARING
68A 118” GB000202 BELT .95 WIDE 118” LG
68B 94” GB000202 BELT .95 WIDE 94” LG
69 4 GP000209 PULLEY ASSEMBLY-3.50
70 1 GP000212 PULLEY ASSEMBLY-3.50
71 2 HC620414 BHSCS .250-20 X .625
72 4 HC700415 BHSCS .375-16 X .75
73 4 HC700416 BHSCS .375-16 X .875
74 2 HC700428 BHSCS .375-16 X 2.25
75 11 HC700430 BHSCS .375-16 X 2.50
76 4 HC700432 BHSCS .375-16 X 2.75
77 2 HF449063 INSERT 3/4 X 1/4-20
78 15 HF540200 GROMMET, NYLON
79 2 HN-60065 NUT, HEX SELF- LOCK .312-18
BLK ZINC
80 21 HN704901 LOCKNUT, .375-16 NYLON
81 18 HS347600 WASHER, SAE .375
82 4 HS387300 LOCKWASHER EXT. TOOTH .500
83 2 HS407100 WASHER, SPRING .650 ID x .790
OD x .062 THK
84 4 HT102214 PHIL, HEX, WASH. HD, TYPE 23,
10-24
85 23 HT542514 PN HD PHIL SC # 8 X .625 BLK
86 2 HX-60184 BALL STUD, .312 - 18 UNC x 10 mm
87 8 HY740000 SET SCREW
88 2 JC620412 BHSCS .250-20 X .50
89 2 JC620422 BHSCS .250-20 x 1.50
90 2 JC660412 BHSCS .312-18 X .50
91 16 JC700412 BHSCS .375-16 X .50
92 4 JC780417 BHSCS .500-13 X 1.00
93 6 JC700420 BHSCS .375-16 X 1.25
94 2 JD343331 S BOLT .500 X 3.50 .375-16
95 1 PP090202 INSERT, PLASTIC 1.50 x 3.00 x 11 GA
96 2 PP090208 INSERT, PLASTIC 1.75 DIA. RIBBED
97 2 PR060005 BUMPER, WEIGHT
98 2 PR069400 BUMPER, RECESS
99 2 PR250203 STRIP, FOAM .12 X .25 X ROLL
100A 2 4605-521 GRIP 1.38 OD X .96 ID 8.25”
100B 1 4605-501 GRIP 1.38 OD X .96 ID 5.00”
101 1 PU060201 BUMPER
102 2 WW150003 WHEEL, 4.00 DIA.
103 1 11040-566 DECAL, SEAT ADJUSTING
104 4 JS347400 LOCKWASHER, INT TOOTH .375
105 2 11040-568 CLAMP BLOCK INSERT
106 2 11000-384 BLOCK, STOP
107 4 JC620415 BHSCS .250-20 X .75
108 1 12040-357 PIN, DETENT
109 1 11040-789 EAGLE PLAQUE
110 4 HN575100 LOCKNUT .190-No 10-24
111 4 HT572512 TAP SC NO. 10-24 X .50 PN HD PHIL
112 1 4800-164 SEAT PAD
113 1 4800-184 BACK PAD W/WEAR COVER
114 1 4800-187 WEAR COVER
115 1 13000-402 MOUNT, WATER BOTTLE HOLDER
116 1 13000-400 HOLDER, WATER BOTTLE
117 1 HT552515 TAP SC NO 8-16X.75
118 2 HT512517 TAP SC 10-24 X 1.00 TYPE WB
119 2 PP090213 INSERT PLASTIC
120 1 11000-407-X* DECAL, INCREMENT WEIGHT
121 1 11040-790 DECAL, MADE IN USA
ITEM QTY PART NO. DESCRIPTION
*Language Key
1-German
2-French
3-Spanish
English
5-Japanese
7-Swedish
8-Russian
