19
3
8
5
6
1
8
3
3
Warning! The supporting leg (3) must always be in direct contact with
the vehicle floor. There must be no objects or spaces between the
vehicle floor and the supporting leg. If there are storage compartments in
the foot well you must contact the vehicle manufacturer.
!
NOTE! Retracting the ISOFIX connectors (4) and using the ISOFIX protection
caps not only prevents damage to the car seat but also protects the ISOFIX system
connectors outside the car from contamination and damage.
• Release the ISOFIX connectors (4) by pressing the red release button (6) and at
the same time pulling the connector rearwards.
• Pull the seat out of the connect guides (2) and push the connectors (4) back into
the exit position.
• By pulling the adjustment handle (8) you can push the supporting leg (3) back
into its exit position and then fold it back to save space.
DEINSTALLATION OF THE CHILD SEAT FROM THE CAR
NOTE! Make sure that CYBEX SIRONA still rests flat on the car seat.
Pull the adjustment handle (8) at the bottom of the supporting leg away and
simultaneously pull the supporting leg (3) out until it touches the vehicle floor.
Afterwards fix the foot in the next longer locking position, to ensure a safe support.
ADJUSTING THE SUPPORTING LEG
Carry out the installation steps in the reverse order.
