23
Turn the seat rearward facing. Please take the supplied rebound bar (34) out of the
packaging. Plug the rebound bar into the appropriate recesses (35) at the rear of
CYBEX SIRONA. Make sure that the side with the screw heads is facing the rear of
the car. An audible „CLICK“ indicates that the rebound bar is properly locked.
The indicator on the headrest (37) shows from which body height of the child the
seat can be recommended for forward facing use.
The seat must only be used forward facing, if the red line is covered by the headrest.
For safety reasons children under this height should only be transported rearward
facing. We recommend to use the seat as long as possible rearward facing.
NOTE! For safety reasons the rebound bar must be installed for rearward facing use
of the CYBEX SIRONA.
NOTE! Only when adjusted to the most suitable height does the headrest (9) offer
your child the highest degree of protection and safety. The height of the headrest
can be adjusted to eleven different positions.
• The headrest (9) must be adjusted to leave a maximum space of two fi ngers width
between the child's shoulders and the headrest (9).
• Activate the adjustable handle (12) on the underside of the headrest (9) and bring
the headrest into the required position.
REARWARDFACING USE 0 KG TO 18 KG
ASSEMBLY OF THE REBOUND BAR
ADJUSTING THE HEADREST
9
12
CLICK!
35
35
37
34
MAX.
