17
HEIGHT AND WIDTH
The innovative size adjustment of the Solution Q-x
automatically adjusts the width of the Shoulder Protection as
the height of the Headrest is adjusted.
After the Solution Q-x is properly installed:
Step 1
Squeeze the orange Backrest Adjustment Handle and adjust
the Backrest to its highest position.
Step 2
Place your child in the booster seat making certain they are
sitting up straight with their back against the Backrest.
Step 3
Adjust the Backrest down until the bottom of the Head
Protection until it is two nger widths above your child’s
shoulders.
Step 4
Release the handle which will lock the Backrest into position.
ADJUSTING THE SEAT FOR YOUR CHILD
ONLY use this booster seat with the bottom of the
Head Protection positioned at two ngers width
above child’s shoulders.
