CyClone Z-020 - Page 4

4
Technical Data
AZ2000
Z-010
Z-011
Z-020
Air Inlet Range
5.0~7.5 Bar
5.0~7.5 Bar
5.0~7.5 Bar
5.0~7.5 Bar
Recommended Air lnlet
6.2 Bar
6.2 Bar
6.2 Bar
6.2 Bar
Rotating Speed Range
1,000~8,000
rpm
3,000rpm
N/A
3500rpm
Air Consumption
80~160 NL/min
(6.2 Bar)
75 NL/min
(6.2 Bar)
140 NL/min
(6.2 Bar)
120 NL/min
(6.2 Bar)
Liquid Capacity
1,000 cc
1,000 cc
1,000 cc
1,000 cc
Cleaner
Neutral, Water-
soluble
Neutral,
Water-soluble
Neutral, Water-
soluble
Neutral, Water-
soluble
Net Weight
0.92 kg
0.62 kg
0.9 kg
0.82kg
Packing Dimension
32*26*12.9cm
32*26*12.9cm
32*26*12.9cm
32*26*12.9cm
Cleaner
• The air-pressure of this Device must be freed before unlocking its cup. And then the
cup can be filled with cleaner.
• Do not use cleaner such as acidic, alkali and/or inflammable. The neutral cleaner is
recommended.
• If cleaner is required to be diluted, please observe the instruction of manufacturer
so that the mixing ratio of a diluted cleaner is correct.
