Cygnus 3 Operating Manual
M4-CYG3-M-ENG_Iss2.doc
12
Connecting the Probe
The Probe is connected to the Gauge with the supplied Probe Cable
as shown below. The Lemo 1 connector is removed by pulling back
on its body, not the cable.
Lemo 1
Probe
BNC Connector
