8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
21 3
1
AUDIO IN
Connect to the audio source equipment (such as DVD player) with a
3.5 mm phone jack for audio signal input.
2
AUDIO SW
This switch allows the user to choose between audio sources. Switch
between the external (EXT) audio input (3.5 mm phone jack) or the
internal (INT) audio from an HDMI to DVI adaptor input.
3
DVI IN/HD TIMING
Connect to the DVI input source such as a PC or laptop with a DVI
cable or with a HDMI cable and HDMI to DVI adaptor.
