6.2 Rear P
anel
POWER
LOCK
SDI OUT
DC 5V
1
4
3
2
1
DC 5V
P
lug the 5
V D
C power supply in
to the unit and connect the adapt
or to
AC w
all outlet.
2
POWER LED
T
his blue LED will illuminate when the device is connected to the
power supply
.
3
L
OCK LED
T
his yellow LE
D will illuminate when both
input source and SDI
output
display has succ
essfully sent and received the sig
nal.
4
SDI OUT
C
onnec
t to the SDI output display
.
8
10
