11
7. CONNECTION DIAGRAM
Option 1: Point to Point
HDMI OUTLAN
POWER
LINK
IR 1
EXTENDER
IR 2
BLASTER
DC 24V
RS-232
OUT
RS-232 In
LAN
HDMI In
HDMI to CAT5e/6 with LAN/IR/RS232
Transmitter
CAT5e/6 Out
Link
IR2 Extender
IR1 Blaster
DC 24V
Power
7m3m 3m
60°
m
m
m
1.5m
60°
1.5m
60°
7m3m 3m
60°
m
m
3m
Internet
Router
LAN Connection
LAN Connection
RS-232
RS-232
RS-232 Equipped
HDMI Switcher
RS-232 Equipped PC
or Notebook
Note: The receiver is
powered via PoC by the
transmitter.
HDMI
Input
HDMI
Output
Power
Supply
Smart TV
IR Extender
IR Extender
DVD/Blu-ray Player
IR Blaster
Single
CAT5e/6/7
Cable
IR Blaster
Compatible
Transmitter
unit with PoC

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the CYP PU-507WPRX and is the answer not in the manual?

CYP PU-507WPRX Specifications

General IconGeneral
Video Bandwidth10.2 Gbps
HDCP SupportHDCP 2.2
HDMI VersionHDMI 1.4
Resolution SupportUp to 4K UHD
Audio SupportDolby TrueHD, DTS-HD Master Audio
Ethernet10/100 Mbps
ControlRS-232, IR
Dimensions25mm (H)
InputHDMI
OutputHDMI
TypeHDBaseT Receiver
