6.2 Receiver Rear Panel
1
1
CAT5e/6/7 IN: Connect to the transmitter unit with a single CAT5e/6/7
cable for transmission of all data signals.
6.3 IR Cable Pin Assignment
3
1
2
3
2
1
Power
IR Blaster Signal
NC
IR Signal
Power
Ground
IR Extender
IR Blaster
