5
6. Specifications
6.1 General Specification
Input Ports 1 x CV/SV, 1 x R/L, 1 x TOSLink (optical fiber)
Output Ports 1 x HDMI, 1 x 3.5mm Phone Jack, 1 x TOSLink
(optical fiber)
Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL
certified)
Remote Control Discrete IR remote
Dimensions (mm) 187(D) x 102(W) x 25(H)
Weight(g) 405
Chassis Material Aluminum
Silkscreen Color Black
Operating Temperature 0°C ~ 40°C
CV/SV INPUT HDMI OUTPUT
SD SD/HD PC
480I/576I (NTSC/PAL) V V
480P/576P V
720P@(50/60) V
1080I@(25/30) V
1080P@(50/60) V
VGA@(60/72/75/85) V
SVGA@(56/60/72/75/85) V
XGA@(60/70/75/85) V
SXGA@(60/75/85) V
UXGA@60 V
WXGA@60(1280x800) V
WSXGA@60(1680x1050) V
WUXGA@60(1920x1200) V
6.2. Support Resolution
DVD
Amplifier
TV
L/R
CV/SV
Optical
Optical / Audio
7. Connection and Installation
