7. CONNECTION DIAGRAM
Amplifi er or HD TV
DVD or Blu-ray Player
RL
AUDIO IN
OPTICAL
DC 5V
POWER
O.V.P
HDCP PATTERN TIMING
SERVICE
HDMI OUTEXITENTERSELECT
SELECT
TIMINGPATTERN
AUDIO25/50
