User Instructions Cyrus AV8
7
GB
GB
WARRANTY
Specifications
Power Supply
Voltage:....................................................................As plate on rear of unit
Power consumption ........................................................................... (15W)
Safety Requirements ...................................................................EN 60065
EMC compliance....................................................... EN55013 & EN55020
Enclosure
Dimensions (WxHxD)..................................................... 215 x 75 x 365mm
Weight.................................................................................................2.8Kg
Material ..............................................................................Die cast chassis
Audio Performance
Analogue Inputs
Input Sensitivity.................................................................................200mV
Input Impedance ................................................................................47kΩ
Input Overload level (1KHz, 0.01%THD)..........................................2.165V
S/N ratio, (500mV i/p, max.vol.)........................................................ 80dBA
THD+N, (500mV i/p, max.vol.).........................................................0.008%
Channel separation (1kHz) ..................................................................99dB
Digital Inputs
Input voltage ...........................................................................500mV pk-pk
Input Impedance ..................................................................................75Ω
S/N ratio, (PCM in, 0dBFS)............................................................... 94dBA
THD+N, (PCM in, 0dBFS)................................................................0.008%
Analogue Outputs
Output voltage...................................................................................380mV
Output Impedance .............................................................................220Ω
Max output voltage................................................................................3.9V
Tape output voltage (PCM in, 0dBFS).....................................................2V
Decoding systems
PCM Stereo, Dolby Pro Logic II, Dolby Digital, DTS
Remote command specification
The remote command specification will be necessary when setting up a
programmable handset with a personal computer.
Transmission protocol:.............................................................. Philips RC5
RC5 Device address............................................................19 (Amplifier 2)
RC5 command list
1 Input 1
2 Input 2
3 Input 3
4 Input 4
5 Input 5
6 Input 6
7 Input 7
8 Input 8
9 Input 9
12 Standby
13 Mute
16 Volume up
17 Volume down
32 Input scroll up
33 Input scroll down
37 Stereo
80 Adjust up
81 Adjust down
83 Exit
88 Noise setup
91 Left front select
92 Centre select
93 Right front select
98 Left surround select
100 Right surround select
110 Input setup
111 Mode setup
118 Subwoofer setup
The warranty card enclosed should be completed by the Dealer and
the purchaser and returned to CYRUS or its Distributor within 8 days
of purchase. No Dealer or Distributor may vary the terms of this
warranty which is personal to the original Purchaser and is not
transferable.
Please retain the sales receipt as proof of purchase.
Warranty claims must wherever possible be made through the Dealer
from whom the equipment was purchased.
This warranty excludes:
• Damage caused through neglect, accident, misuse, wear and
tear, or through incorrect installation, adjustment or repair by
unauthorised personnel. Any unauthorised servicing will result in
loss of guarantee.
• Liability for damage or loss occurring in transit to or from the
purchaser.
• Consequential damage, loss or injury, arising from or in
conjunction with this equipment.
Equipment for attention under warranty should be consigned return
carriage paid. If returned equipment is found to comply with the
published specification, CYRUS reserves the right to raise a charge.
The above conditions do not affect your statutory rights as a
consumer.
