Product User’s Manual – MD13S
3. BOARD LAYOUT AND SPECIFICATION
Label
Function
A
Terminal Block
B
MA LED Indicator
C
MB LED Indicator
D
MA Test Switch
E
MB Test Switch
F
Input pin
G
Power LED Indicator
H
OC LED Indicator
I
ERR LED Indicator
J
SMD Compatible
