Product User’s Manual – MD30C
External Switches and Potentiometer
Set the jumpers as below:
JP4 : EXT POT
JP6 : INT PWM
Connect the external switches and potentiometer as below. Please note that the onboard
potentiometer will have no effect when JP4 is changed to EXT POT. The recommended
resistance for external potentiometer is 10K Ohm.
