RMS (Average) Power Handling :
Program Power Handling :
Peak Power Handling :
Recommended Amplifier:
On-axis Frequency Range :
Nominal Impedance:Minimum Impedance :
On-axis Sensitivity 1W / 1 m :
Rated Peak SPL at Full Power:
Nominal -6 dB Beamwidths :
(average, 500 Hz to 8 kHz)
R
P
K
F
I
S
B
MONITOR 6
100 W
200 W
> 400 W
100Wto200Wat8ohm
44 Hz - 40 kHz
8 ohm
7.2 ohm (at 175 Hz)
85 dB SPL
111 dB
125° Horizontal
105° Vertical
MONITOR 8
125 W
250 W
> 500 W
125Wto250Wat8ohm
38 Hz - 33 kHz
8 ohm
3.2 ohm (at 15 kHz)
89 dB SPL
116 dB
120° Horizontal
95° Vertical
Enclosure Material:
Color:
Connectors:
Dimensions (HxWxD):
Mounting:
Weight:
Shipping Weight:
R
P
K
F
I S
B
Based on a 2 hour test usinga6dBcrest factor pink noise signal bandlimited according to IEC 268-1 (1985).
Conventionally 3 dB higher than the RMS measure, although this already utilizes a programme signal.
Corresponds to the signal crests for the test described in .
As per IEC 268-5 (1989), re. a two octave band centred at 8 kHz. Half space anechoic.
In practice cable and connector impedance has to be added to all impedance values. IEC average between 200 Hz and 8 kHz.
Average of one-third octave band measures. Computed from polar information measured at two degree angular and 1/24th octave
frequency resolution. AUTOPOL, a platform consisting of custom and customized hardware and software, was used for the automated
high-resolution acquisition and post-processing of directivity data. The digital storage of the data allows further processing and
conversion to other software formats. Modeling data for EASE and other software can be found at http://www.dasaudio.com/.
R
MDF with stripped Iroko wood side panels
Black/Iroko wood
Safety bare wire connectors
34x23x27cm
(13.5 x 6.5 x 10.5 in)
42x28x29cm
(16.5 x 11 x 11.5 in)
2 x M6 points
6.9 kg (15.2 lbs)
8.1 kg (18.8 lbs)
12.8 kg (28 lbs)
14 kg (31 lbs)
