D-Box 4400i User Manual

2 of 18
TABLE OF CONTENTS
Important Safety Instructions 3
1- D-BOX 4250i/4400i, 3 axis actuators system overview 4
2- D-BOX 4250i/4400i system dimensions and setup 4
3- Positioning the components 7
4- Positioning the actuators (Bottom view of seating) 8
5- Arm Rest mounting hole dimensions 9
6- Setting up the actuators in the seat 9
7- Connecting the actuators to the ACM (Actuator Control Module) 10
8- D-BOX 4250i/4400i Electrical diagram 12
9- Pictures of D-BOX installation (in a loveseat) 13
Appendix 1 – Installation of the ACM bracket 18
The 4250i may be installed in a single seat and loveseat only. The 4400i may be installed in
a single seat, loveseat and 3 seats sofa.
WARNING: DO NOT USE ANY ATTACHMENTS THAT ARE NOT RECOMMENDED BY THE
MANUFACTURER, AS THEY MAY CAUSE DAMAGE OR MALFUNCTIONS.

D-Box 4400i Specifications

General

Brand	D-Box
Model	4400i
Category	Controller
Language	English
