Appendix C - IP Address Configuration
To connect to a network, make sure the proper
network settings are configured for DWL-G510.
For Microsoft Windows XP:
Go to Start > right click on My Network Places >
select Properties > Double-click on the Network
Connection associated with the DWL-G510.
Input a static IP address in the same range
as the Wireless Router or Access Point.
Static IP Address setup
Click OK
IP address: 192.168.0.52
Subnet mask: 255.255.255.0
Click OK
Click Internet Protocol (TCP/IP)
Click Properties
Select Obtain an IP address
automatically (if the Wireless
Router or Access Point has DHCP
server enabled)
Select Obtain DNS server
address automatically
Dynamic IP Address setup
Used when a DHCP server is available on
the local network. (i.e. Router)
Used when a DHCP server is not available
on the local network.
Select Use the following IP address
To Next Page
