3
Mounting the Antenna (optional)
A.
Wall Mounting:
Step 1: Identify a mounting location and place the
sticker on.
Step 2: Use a 4/16”drill bit to drill holes at 2 marked
places on sticker.
Step 3: Tap the plastic anchors gently into the hole
by using a rubber mallet or hammer.
Step 4: Use a screwdriver to secure the screws into
the plastic anchors.
Be sure to leave enough space so the antenna
base will slide over the head of the screw.
Step 5: Place the antenna base over the screw and
slide it into the locking position.
B.
Magnetic Mounting:
Step 1 : Identify a mounting location which is
available for magnetic using.
For example: Office partition, white board,
etc.
Be sure not to place antenna onto monitor,
hard disk, notebook, etc.
C.
Desktop:
D.
Attach to AP/Router:
