9
Technische Daten:
1. Elektrische Eigenschaften:
Frequenzbereich 2,42-2,4835 GHz
Impedanz 50Ω, normal
Stehwellenverhältnis (VSWR) max. 1,92
Rückflussdämpfung max. -10 dB
Antennenstruktur Kollinear-Antenne
Peak-Gain (ohne Kabelverlust) 7 dBi
Zulässige Leistung 1 W
Kabelverlust (1,5 m) 2,1 dB bei 2,45 GHz
E-Ebene 24 Grad
H-Ebene 360 Grad
2. Physical Properties:
Kabel RG-178 50Ω
Kabellänge 1,5 m
Kabelfarbe Grau
Anschluss Reverse-SMA-Anschluss
Produktmaterial ABS, ABS+PC
Betriebstemperatur -20 °C - +65 °C
Lagertemperatur -30 °C - +75 °C
Farbe Antenne: metallic-grau und
silber Fuß: metallic-grau
