4
Specifications
1. Electrical Properties:
Frequency Range 2.42GHz~2.4835GHz
Impedance 50Ω Normal
VSWR 1.92 Max
Return Loss -10 dB Maximum
Antenna Structure Collinear antenna
Peak Gain ( w/o cable loss) 7dBi
Admitted Power 1 W
Cable loss( 1.5m) 2.1dB@2.45GHz
E-Plane 24 deg.
H-Plane 360 deg.
2. Physical Properties:
Cable RG-178 50Ω
Cable length 1.5 M
Cable color Gray
Connector Reverse SMA plug
Product material ABS,ABS+PC
Operating Temp -20°C ~ +65°C
Storage Temp -30°C ~ +75°C
Color Antenna: Metallic gray and silver
Base: Metallic gray
D-Link wireless antenna series are optional passive accessories for the
suitable wireless devices. Prior to your usage of the wireless antenna,
please refer the wireless device user manual, make sure the antenna
connector type, frequency band, indoor or outdoor device usage is
compatible between the antenna and device. When installing an external
antenna, the total output power (EIRP) is the sum of device output
power and antenna gain minus any connector or cable loss signal loss.
The total output power (EIRP) must be equal or less than 20dBm to be
in compliance of ETSI R&TTE regulation. We highly recommend that
you seek professional help if you are unsure of whether or not your
wireless installation is within regulation. Please note that all wireless
products may cause interference which could affect the functioning of
radio navigation service or other safety services, or otherwise seriously
degrades, obstructs or repeatedly interrupts a radiocommunications
service operating in accordance with the applicable legislation. In case
of interference with radio equipments, the user may be required to take
adequate measures including repositioning the wireless devices or
changing the wireless LAN configuration.
