D-Link DCS-2210/DCS-2230 Quick Install Guide
2
DCS-2210/DCS-2230 Quick Install Guide
This installation guide provides basic instructions for installing the DCS-2210/DCS-2230
Network Camera on your network. For additional information about how to use the camera,
please see the User’s Manual which is available on the CD include in this package or from the
D-Link support website.
Installation Steps
1. Verify the package contents against the list below.
2. Hardware Overview
3. Hardware Installation
4. Conguration with Wizard
1. Package Contents
 DCS-2210 or DCS-2230 Full HD PoE Network Camera
 Camera Stand
 Manual and Software on CD-ROM
 CAT5 Ethernet Cable
 Power Adapter
 Quick Install Guide
If any of the above items are missing, please contact your reseller.

D-Link DCS-2210 Specifications

General

Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	480p, 720p
Video formats supported	H.264, M-JPEG, MPEG4
Supported graphics resolutions	1280 x 960, 1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/2.7 \
Effective sensor resolution	2000000 pixels
Optical zoom	- x
Zoom capability	Yes
Security algorithms	HTTPS
Built-in HDD	No
Compatible memory cards	SDHC
LED type	IR
Form factor	Box
Product color	White
Certification	CE, CE LVD, FCC, ICES-003, C-Tick
Placement supported	Indoor
Connectivity technology	Wired
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Audio system	2-way
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4, TCP/IP, UDP, ICMP, DHCP Client, NTP Client (D-Link), DNS Client, DDNS Client (D-Link), SMTP Client, FTP Client, HTTP / HTTPS, Samba Client, PPPoE, UPnP Port Forwarding, RTP/RTSP/RTCP, IP filtering, 3GPP, IGMP, ONVIF
Networking features	Fast Ethernet
Compatible operating systems	Microsoft Windows 7/Vista/XP/2000 Apple MAC OSX 10.3+ Linux, Unix
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
DC output current	1.25 A
DC output voltage	+5V
Power source type	PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	2 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	38.7 mm
Width	58 mm
Height	95 mm
Weight	69 g
