FAQs
1. How do I change the accent ring?
Rotate the access ring counter clockwise, then lift it o. Put the new ring on and rotate it
clockwise until it clicks into place.
2. How do I select a dierent lullaby?
Use the mydlink Baby app to change the lullaby. Tap on the Music icon on the cameras
Live View screen. Choose a lullaby from the list, or you can select Play All.
3. I started the mydlink Baby Camera Monitor app, but I cant nd my camera.
Make sure your camera is turned on and receiving power.
If you have set up your camera before, make sure your smartphone or tablet is connected
to the same router as your camera.
If you are setting up a new camera, make sure your smartphone or tablet is connected
to the cameras Wi-Fi network (not to your wireless router). This also applies when you
enable Direct Connect to use the camera away from home. (See the Advanced Features
section of the User Manual for details.)
The Wi-Fi network name should be [myBabyCam-XXXX], where XXXX is a 4-digit code
(the last 4 digits of your camera’s MAC address).
The Wi-Fi password is printed on a label on the bottom of your camera.
You can also nd your cameras Wi-Fi network details on a label attached to the back
of this Quick Install Guide.
If you still can’t nd your camera, reset your camera by pressing its reset button for 10
seconds while your camera is plugged in (see question 6 below).
4. What does it mean when the Power LED is red?
When you power on the camera, the Power LED will be solid red. When you reset the
camera, the Power LED will be ashing red.
5. Why do I see a white haze when viewing Live Video in night vision mode?
The night vision light on the camera may be reecting o a nearby surface. Try
repositioning and aiming the camera.
6. What can I do if I forget my password?
If you forget your password, you must reset the camera.
Unfortunately, this process will change all your settings back
to factory default. To reset the camera, locate the reset button
on the back of the camera. With the camera powered on, use
an unfolded paper clip to hold the button down for 10 seconds.
Reset
8

Other manuals for D-Link DCS-850L

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DCS-850L and is the answer not in the manual?

D-Link DCS-850L Specifications

General IconGeneral
LED typeIR
Night modeYes
Sensor typeCMOS
Digital zoom4 x
Video resolutions320 x 240, 640 x 480 pixels
Fixed focal length2.44 mm
Optical sensor size1/4 \
Night vision distance4.8 m
Pan range-170 - 170 °
Maximum range- m
Tilt angle range-25 - 95 °
Number of lullabies5
Image formats supportedJPG, MJPEG
Mobile operating systems supportedAndroid 4.1, Android 4.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, iOS 6.0, iOS 6.1, iOS 7.0, iOS 8.0, iOS 8.2, iOS 9.0
Night-light-
Product colorBlue, Pink, White
Power source typeBattery, USB
InterfaceWi-Fi
Wi-Fi standardsWi-Fi 4 (802.11n)
USB connector typeMicro-USB
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (receiver)20 - 80 %
