Hardware Installation
System Requirements
• Java Enabled and Compliant Web Browser
• CPU: Pentium III, 850MHz or above
• Memory Size: 128MB
• VGA card resolution: 800x600 or above
• Existing 10/100Mbps Ethernet-Based Network
Connect the Ethernet Cable
Connect the included Ethernet cable to the network
cable connector located on the back panel of the
DCS-900 and attach it to the network. Network
Connectivity is confirmed when the orange LED
Indicator on the DCS-900 located below the Power
LED is illuminated.
Attach the External Power Supply
Attach the external power supply to the DC power
input connector located on the rear panel of the
DCS-900 and connect it to your local power supply.
Note: Power source is confirmed when the green
LED Power Indicator located to the right of the lens
on the DCS-900 is illuminated.
Attach the Swivel Stand
Locate the stand connector on the bottom panel of
the DCS-900 and screw on the swivel stand to the
base of the DCS-900.
