1. What is a mydlink No.? What is it used for?
Each camera has a unique eight-digit mydlink number which will be shown
on the label on the back of your camera. This eight-digit number identies
your device, and is required to add your device to your mydlink account.
2. What can I do if my DCS-934L is not working correctly?
Try using the Setup Wizard.
To make sure your hardware is installed correctly, make sure that:
- the power LED is lit solid green
- your Internet connection is working
- your routers LAN & WAN connections are okay
- your router supports UPnP
®
- your camera is on the same network as your PC
- both your PC and camera have a working Internet connection
If your camera is still not working, check your router and make sure it has
the latest rmware.
3. What can I do if I forget my password?
FAQs
If you forget your password, you must reset the
camera. Unfortunately, this process will change
your settings back to factory default. To reset the
camera, locate the reset button on the back of
the camera. With the camera powered on, use an
unfolded paper clip to hold the button down for
10 seconds.
Reset
Button
4. Why is there a white haze when viewing in night vision mode?
When viewing in night vision mode, the IR lights on the camera may be
reecting o a nearby surface. Try repositioning the camera in order to avoid
glare from IR LEDs.
10
