DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
Appendix C
Cable Lengths
Use the following table to as a guide for the maximum cable lengths.
Standard Media Type Maximum Distance
Mini-GBIC 1000BASE-LX, Single-mode fiber module
1000BASE-SX, Multi-mode fiber module
1000BASE-LHX, Single-mode fiber module
1000BASE-ZX, Single-mode fiber module
10km
550m
40km
80km
1000BASE-T Category 5e UTP Cable
Category 5 UTP Cable (1000 Mbps)
100m
100BASE-TX Category 5 UTP Cable (100 Mbps) 100m
10BASE-T Category 3 UTP Cable (10 Mbps) 100m
219
