D-Link DFM-560EL

Hardware Installation
Please unplug the telephone Line and plug the telephone line into the
socket on the back of the modem marked LINE.
POWER ADAPTER
External Modem Diagram
WALL SOCKET
Power Switch
Power Jack
Telephone Line
Socket
RS-232C
Connect
