3
Restart Your Computer
Connecting Additional Computers To
The DI-808HV
Using additional Ethernet (CAT5 UTP) cables, connect your Ethernet-equipped
computers to the remaining Ethernet LAN ports on the back panel of the DI-808HV.
Power LED – a solid
light indicates a proper
connection to the
power supply.
WAN LED – a solid
light indicates
connection on the
WAN port. This
LED blinks during
data transmission.
Local Network LEDs – a solid
light on the port indicates a
connection to an Ethernet
enabled computer on ports 1-8.
This LED blinks during data
transmission.
Status Status
Status Status
Status – will flash
consistently to indicate
that the DI-808HV is
working properly.
COM LED – a solid light
indicates a proper
connection to a dial-up
modem.
The LAN Ports on the DI-808HV are Auto MDI/MDIX. Meaning you can
use a straight-through or crossover Ethernet cable in the LAN Ports.)
