D-Link DIR-300A - Page 35

DIR-300A Quick Installation Guide
Wireless Module Parameters
Transmitter output power
The maximum value of the
transmitter output power
depends upon the radio
frequency regulations applied in
your country
· 802.11b (typical at room temperature 25 °C)
17dBm (+/-1.5dB) at 1, 2, 5.5, 11Mbps
· 802.11g (typical at room temperature 25 °C)
17dBm (+/-1.5dB) at 6, 9, 12Mbps
16dBm (+/-1.5dB) at 18, 24Mbps
15dBm (+/-1.5dB) at 36, 48, 54Mbps
· 802.11n (typical at room temperature 25 °C)
HT20
16,5dBm (+/-1.5dB) at MCS0/1/2
16dBm (+/-1.5dB) at MCS3/4
15,5dBm (+/-1.5dB) at MCS5
15dBm (+/-1.5dB) at MCS6
14dBm (+/-1.5dB) at MCS7
HT40
16,5dBm (+/-1.5dB) at MCS0/1/2
16dBm (+/-1.5dB) at MCS3/4
15,5dBm (+/-1.5dB) at MCS5
15dBm (+/-1.5dB) at MCS6
14dBm (+/-1.5dB) at MCS7
35
