D-Link DIR-601 - Hardware Overview; Connections

4D-Link DIR-601 User Manual
Section 1 - Product Overview
Hardware Overview
Connections
1 LAN Ports (1-4) Connect Ethernet devices such as computers, switches, and hubs.
2 Internet Port
The auto MDI/MDIX Internet port is the connection for the Ethernet cable to the cable or DSL
modem.
3 Power Receptor The Power LED will illuminate red when the camera is receiving power.
4 Reset Pressing the Reset button restores the router to its original factory default settings.
41 32
